Fire Pocket Door Frame
Product Code: E19430
Fire Pocket Door Frame
Product Code: E19430
Fire Rated Pocket Door System
This fire-rated pocket door frame has been designed specifically to allow you to use any 30-minute fire-rated door (FD30 ). It includes all the benefits of the standard Classic Pocket Door System plus a specially designed jamb kit made from a very particular hardwood called Pterygota commonly known as Koto (supplied unfinished) and pre-treated with intumescent primer.
- For use with 44mm FD30-rated fire doors (not included)
- Maintenance-free track and runners.
- Fully adjustable front and rear doorstop.
- Runners are tested to 100,000 cycles (that’s around 25 years of average use!)
- Anti-warp door profile
- 100mm Jambs (wall thickness)
- Self-centering floor guide
- 15-year guarantee on the complete Eclisse steel pocket system and runners
- Fully tested and approved by International Fire Consultants PAR/10057/01
- Compatible with our self-closing mechanism
- Compatible BIAS Anti Slam Soft Close Mechanism
- Choose from white or brown intumescent seals
- Door jambs need to be finished with fire-retardant paint.
OPTIONAL ACCESSORIES :
- Back of the door self-closer - self-closing mechanism is an ingenious device, that fixes to the back of the door and allows the door to close by itself
- Allows the door to close by itself, automatically - with no input from you!
- Can be installed retrospectively
- The system allows you to adjust the closing speed
Before ordering please refer to the Field of Application Report and your Building Inspector with respect to whether installation of the fully approved self-closing mechanism is required for your application.
Overall Frame Dimensions with Door Panel Sizes (Width x Height)
Imperial Door Sizes
610 x 1981 Door Panel = 1273 x 2056 mm Pocket Frame
686 x 1981 Door Panel = 1449 x 2056 mm Pocket Frame
762 x 1981 Door Panel = 1625 x 2056 mm Pocket Frame
838 x 1981 Door Panel = 1701 x 2056 mm Pocket Frame
915 x 1981 Door Panel = 1888 x 2056 mm Pocket Frame
Metric Door Sizes
626 x 2040 Door Panel = 1288 x 2115 mm Pocket Frame
726 x 2040 Door Panel = 1488 x 2115 mm Pocket Frame
826 x 2040 Door Panel = 1688 x 2115 mm Pocket Frame
926 x 2040 Door Panel = 1888 x 2115 mm Pocket Frame
Made for use with standard UK door sizes, can be supplied in made-to-measure. options. Please contact us for more information on bespoke options
